NEWSTAR LED Co.,Limited

About Us

Newstar LED Co.,Limited(Newstar LED) is manufacturer & supplier in China which is specialized in Addressable LED Strip lighting since 2009. We mainly produce Digital LED and LED Strip and normal LED Strip. All of our LED products are high quality with perfect heat dissipation, long life span, low light decay and high luminous intensity.

Quality Control：Newstar LED’s operation strictly follow the ISO 9001:2015 standard. The LED we packed by ourselves are all with golden wire and copper frame to assure a steady and top-grade quality.

R&D：Newstar LED always focus on R&D and improving the production of high quality LED product. With 12 people engineers team, we developed the IC of HD108, HD107S, APA107 and customized over 3000 different products as per our customer's needs.

Service：Newstar LED started to do export since 2009, some of our colleagues are with more than 10 years experience, which will understand your needs and concerns well.

Newstar LED is willing and ready to be your honest partner. Let's make our life brighter and more colorful!

Addressable LED Strip

Normal LED Strip

Addressable LED Chip

Neon LED Strip

THE LATEST HOT-SELLING PRODUCTS

120leds HD107S 2020 LED Strip 6mm PCB DC5V Waterproof IP67

● LED internal integrated high quality external control line serial cascade constant current IC; 5V application; default on electric lights; ● The two-wire synchronous control. ●The three RGB output control, 8Bit (256) color; 5Bit (32) to adjust the brightness; ● The three constant current drive, self detection function specific signal ● The maximum frequency of 40MHZ serial data input ● The double data transmission, built-in support uninterrupted oscillation PWM (28Khz) output, can maintain a static image.

RGB COB LED Strip Full Color 840leds/m 15w/m

Dot-free RGB COB Strip Light spec: LEDs per Meter: 840pcs Voltage: DC24V Watt: 15W/M Led type: COB LED CRI: >80Ra PCB Width: 10mm PCB Thickness: 2Oz Led lighting angle: 180° IP Grade: IP20, Extruded IP65, IP67 with Silicone tube or shrinkable sleeve, IP68 with Silicone tube and glue.

HD107S 2020 Flexible LED Strip 200leds 10mm PCB 2020 Pixel Strip

HD108 16bit 2020SMD LED Strip Flexible PCB 10MM High Density 200LEDs Per Meter

● Top SMD internal integrated high quality external control line serial cascade constant current IC; 5V application; default on electric lights; ● Control circuit and the RGB chip in SMD 5050 components, to form a complete control of pixel, color mixing uniformity and consistency; ● The Two-wire synchronous control, built-in bi-directional transmission function. ●RGB three-color output control, 64Bit (65536 level) color settings; each set of data are 1bit start code +15 Bit (32) brightness adjustment (red, green, blue three ports each 5bits, corresponding to S4 ~ S0) ; 48bits gray data (red, green, blue 16bits) composition.

High Density 320LEDs HD107S 2020 Flexible Pixel LED Strip 8mm PCB DC5V

HD107S transmission speed 40MHz and PMW refresh rate >27KH Better than APA102 (APA102 with transmission speed 20MHZ and PMW 20KHz) HD107S performance is more stable with low defective rate

Super High Efficiency ERP-Friendly LED Strip

Regarding the NEW ERP regulation, we can solve it all for you. Currently our highest brightness LED Strip can be ERP Class B, and we also have ERP class D/E series for choice. Meanwhile, we can provide a super competitive price for you to expand the business. Be our customer, we can solve all for you.

WS2815 Pixel LED Screen 2121smd 5050smd DC12V White PCB Stable performance

WS2815 Pixel LED Screen works very good and stable, as we know, WS2815 has two data wires, when one led failed, it won't affect the whole product work. That's the biggest advantage to do a high density Pixel LED Screen.

SK6812 DC12V RGBW Pixel LED Strip Individually Addressable

THE LATEST NEWS AND R&D

HD107S LC8823 2020 LED on promotion

Good news, currently, HD107S(LC8823) 2020 LED is under promotion, price is the lowest ever on market, welcome to contact us for quotation.

2024 New Year Holiday Information.

Year end is coming, our traditional New Year holiday will start from 3rd to 17th February, total 15days, we'll be back to work on 18th February.

Comparison of APA102 and HD107S Pixel LED

In summary, HD107S offers a better performance on both PWM frequency, transmission speed and brightness, these are key differences that make HD107S more popular for different applications. The APA102 is an established, reliable product that offers high-speed data transmission at cheaper price point. The HD107S, on the other hand, has a higher refresh rate, a higher transmission speed, and better color consistency and higher brightness, making it ideal for high-speed applications that require precise timing and color matching.
